Refrigerator Compressor by Product Line Inverter Standard Commercial Vestar

Refrigerator Compressor Series by Product Line OEM

Introduction:

Title: Three Product Lines – Complete Technical Specifications

Product Line	Technology	Capacity Range	COP Range	Key Features	Target Applications
High-Efficiency Inverter Series	Inverter Linear / Inverter Rotary	60W – 400W	1.55 – 2.15	Variable speed (1200‑4500rpm), ultra‑quiet (32‑36dB), precise temp control, energy savings up to 40%, R600a/R134a	French door, side‑by‑side, built‑in, premium refrigerators
Standard Fixed-Speed Series	Reciprocating / Fixed Rotary	50W – 300W	1.45 – 1.60	Proven reliability, simple construction, economical, PTC/RSIR start, R134a/R600a	Mini fridges, dorm refrigerators, top‑mount, replacement market
Commercial / High-Capacity Series	Reciprocating / Rotary	150W – 500W	1.50 – 1.85	High starting torque, low‑temp capability (-30°C), continuous duty, R290/R404A/R134a	Chest freezers, commercial display cases, walk‑in coolers, food service

UL/ETL certified – all models meet North American safety standards
115V/60Hz – standard for North American refrigeration (12/24V DC options available)
Refrigerants: R134a, R600a, R290, R404A – low GWP options across all lines
20 years appliance manufacturing – consistent quality, reliable supply

Product Details

Vestar Refrigerator Compressor Series – By Product Line

Product Line	Model	Technology	Cooling Capacity (W)	Cooling Capacity (BTU/h)	Power Input (W)	COP	Refrigerant	Voltage	Speed (rpm)	Sound (dB)	Displacement	Application	Key Feature
High-Efficiency Inverter	VRI‑60	Inverter Linear	60	205	38	1.58	R600a	115V/60Hz	1200‑4500	32	5.96 cc	Mini fridge, compact	Variable speed, ultra‑quiet
High-Efficiency Inverter	VRI‑80	Inverter Rotary	80	273	48	1.66	R600a	115V/60Hz	1200‑4500	33	6.5 cc	Compact refrigerator	High efficiency
High-Efficiency Inverter	VRI‑120	Inverter Linear	120	410	68	1.76	R600a	115V/60Hz	1200‑4500	33	7.2 cc	Top‑mount refrigerator	Precise temp control
High-Efficiency Inverter	VRI‑150	Inverter Rotary	150	512	83	1.80	R600a	115V/60Hz	1200‑4500	34	8.0 cc	Top‑mount, bottom‑mount	Energy savings 30%
High-Efficiency Inverter	VRI‑200	Inverter Linear	200	682	105	1.90	R600a	115V/60Hz	1200‑4500	34	8.8 cc	Bottom‑mount refrigerator	COP up to 2.00
High-Efficiency Inverter	VRI‑250	Inverter Linear	250	853	125	2.00	R600a	115V/60Hz	1200‑4500	35	10.6 cc	Side‑by‑side, French door	Premium efficiency
High-Efficiency Inverter	VRI‑300	Inverter Linear	300	1,023	146	2.05	R600a	115V/60Hz	1200‑4500	35	11.0 cc	Large capacity, built‑in	Smart ready
High-Efficiency Inverter	VRI‑350	Inverter Linear	350	1,194	168	2.08	R600a	115V/60Hz	1200‑4500	36	12.0 cc	Built‑in, premium	Maximum efficiency
Standard Fixed-Speed	VRS‑55	Reciprocating	55	188	58	0.95	R134a	115V/60Hz	3000 fixed	42	4.0 cc	Mini fridge, wine cooler	Low cost, reliable
Standard Fixed-Speed	VRS‑70	Reciprocating	70	239	67	1.05	R134a	115V/60Hz	3000 fixed	43	4.5 cc	Dorm fridge, beverage	Simple construction
Standard Fixed-Speed	VRS‑95	Reciprocating	95	324	79	1.20	R134a	115V/60Hz	3000 fixed	44	5.0 cc	Compact refrigerator	PTC start
Standard Fixed-Speed	VRS‑112	Reciprocating	112	382	91	1.23	R134a/R600a	115V/60Hz	3000 fixed	44	5.5 cc	Compact refrigerator	RSIR motor
Standard Fixed-Speed	VRS‑135	Reciprocating	135	461	103	1.31	R134a/R600a	115V/60Hz	3000 fixed	45	6.0 cc	Top‑mount refrigerator	Proven reliability
Standard Fixed-Speed	VRS‑170	Reciprocating	170	580	126	1.35	R134a/R600a	115V/60Hz	3000 fixed	46	6.5 cc	Top‑mount refrigerator	High torque
Standard Fixed-Speed	VRS‑205	Reciprocating	205	700	146	1.40	R134a/R600a	115V/60Hz	3000 fixed	47	7.0 cc	Large top‑mount	LBP application
Commercial Series	VRC‑150C	Reciprocating	150	512	115	1.30	R134a	115V/60Hz	3000 fixed	48	8.0 cc	Display case	Continuous duty
Commercial Series	VRC‑200C	Reciprocating	200	682	148	1.35	R134a/R290	115V/60Hz	3000 fixed	49	9.0 cc	Walk‑in cooler	High starting torque
Commercial Series	VRC‑250C	Rotary	250	853	175	1.42	R290	115V/60Hz	3000 fixed	47	10.0 cc	Chest freezer	Low‑temp to -30°C
Commercial Series	VRC‑300C	Rotary	300	1,023	200	1.50	R290	115V/60Hz	3000 fixed	48	11.0 cc	Freezer, merchandiser	R290 optimized
Commercial Series	VRC‑400C	Reciprocating	400	1,365	266	1.50	R404A/R290	115V/60Hz	3000 fixed	52	14.0 cc	Commercial freezer	Extended range
Commercial Series	VRC‑500C	Reciprocating	500	1,706	333	1.50	R404A/R290	115V/60Hz	3000 fixed	54	16.0 cc	Walk‑in freezer	Heavy duty

Product Line Comparison

Product Line	COP Range	Efficiency vs Standard	Noise Level	Initial Cost	Best Applications
High-Efficiency Inverter	1.58 – 2.08	30‑40% higher	32‑36 dB	$$$$	Premium refrigerators, energy‑saving designs, quiet operation priority
Standard Fixed-Speed	0.95 – 1.40	Baseline	42‑47 dB	$	Entry‑level, price‑sensitive markets, replacement, simple designs
Commercial Series	1.30 – 1.50	10‑15% higher	47‑54 dB	$$	Freezers, commercial units, continuous duty, low‑temp requirements

Performance at Different Speeds (Inverter Models)

Model	Speed (rpm)	Cooling Capacity (W)	Power Input (W)	COP	Application
VRI‑150	1200	96	58	1.66	Low load, energy saving
VRI‑150	2000	142	83	1.72	Normal operation
VRI‑150	3000	218	130	1.68	High demand
VRI‑150	4500	290	175	1.66	Pull‑down, maximum cooling

Refrigerant Options by Product Line

Refrigerant	Type	GWP	Inverter Series	Standard Series	Commercial Series	Notes
R600a	HC (isobutane)	3	★★★★★	★★★★	★★	Optimal for efficiency, quiet operation
R134a	HFC	1,430	★★	★★★★★	★★★★	Traditional, replacement market
R290	HC (propane)	3	★★★	–	★★★★★	Best for low‑temp, high capacity
R404A	HFC	3,922	–	–	★★★	Legacy commercial, being phased down

Application Temperature Ranges

Product Line	Evaporating Temp Range	Condensing Temp Range	Best For
High-Efficiency Inverter	-25°C to -5°C	35°C – 50°C	Fresh food compartments, variable load
Standard Fixed-Speed	-25°C to -5°C	40°C – 55°C	Standard refrigerators, stable load
Commercial Series	-35°C to -5°C	40°C – 55°C	Freezers, low‑temp applications

OEM/ODM Capabilities

Service	Description
Product Line Selection	We help select the optimal compressor line for your target market and performance requirements.
Custom Performance Matching	Match compressor specifications to your refrigerator design (capacity, efficiency, refrigerant).
Private Labeling	Your logo, branding, and custom part numbers on compressor housing and packaging.
Mixed Container Orders	Combine any product line models in one 40HQ container – optimize inventory.
Technical Documentation	Performance curves, submittal drawings, wiring diagrams, and installation guides.
DC Voltage Options	12V and 24V DC models available for RV, marine, and off‑grid applications.

Certifications & Compliance

UL / ETL (North America) – all models
IEC 60335 safety standard
RoHS / REACH compliant
DOE and NRCAN energy efficiency standards
CCC / CB / VDE available (export models)

[Contact our sales team for product line selection assistance and volume pricing.]
